Description
The Meritor M85919 is a standard heavy-duty shock absorber engineered to OEM specifications for truck suspension applications. It features a 60.5 mm (2.38 in.) body diameter, a 40 mm (1.57 in.) bore, and a 204 mm (8.03 in.) stroke. Collapsed length is 369 mm (14.53 in.); extended length is 573 mm (22.55 in.). The 70 mm (2.75 in.) dust shield protects the piston rod, and the unit includes a hydraulic stop. Sold individually. Cross-references include Gabriel 85919, Monroe 65503 and 74429, Dayton Parts M65503, and Automann A85919. Call us to confirm proper fit for your suspension setup.
Features
Body diameter: 60.5 mm (2.38 in.)
Bore: 40 mm (1.57 in.)
Stroke: 204 mm (8.03 in.)
Collapsed length: 369 mm (14.53 in.)
Extended length: 573 mm (22.55 in.)
Dust shield diameter: 70 mm (2.75 in.); hydraulic stop included
Tech Specs
- Body Diameter: 60.5 mm (2.38 in.)
- Bore: 40 mm (1.57 in.)
- Stroke: 204 mm (8.03 in.)
- Collapsed Length: 369 mm (14.53 in.)
- Extended Length: 573 mm (22.55 in.)
- Dust Shield Diameter: 70 mm (2.75 in.)
- Hydraulic Stop: Yes
- Type: Standard
- Unit Pack: 1
Additional Information
Cross-reference / interchange part numbers for Meritor M85919: Gabriel 85919 or GAB85919, Monroe 65503 (also MO65503 or TEN65503) and 74429, Dayton Parts Batco M65503, Automann A85919, Meritor alternate A7805L1000, Wabash Trailer 203447, and additional references 202447, MER202447, MERM85919, HS85919, TDAM85919, 7805X1012, 316488, 606655, 680672, 60998002, 59483000, 1617759000. Call us to verify the correct application before ordering.
