Description
Description: Steering Angle Sensor
Condition: New
Brand: Bendix®
Part Number: K151574
- Weight: 3 lbs
- Fit for: Kenworth, Peterbilt
- Specifications:
- Model: SAS-80X
- Overvoltage: 24 Volts
- Baud rate: 250 Kilobaud
- Current maximum: 150 mA
- Connector orientation: Straight
- Connector type: 7-Pin connector (male)
- Operating voltage range: 8 VDC – 16 VDC
- Minimum operating temperature: -40 °F (-40 °C)
- Maximum operating temperature: 185 °F (85 °C)
- Functions:
- Ecu communication: The sensor transmits the measured steering angle data to the ECU.
- Steering angle measurement: The sensor continuously measures the angle of the steering wheel as it is turned.
- Vehicle stability control: The sensor can also be used as part of vehicle stability control systems to help prevent loss of control during sudden maneuvers.
- Diagnostic purposes: The sensor can be used for diagnostic purposes to identify problems with the steering system, such as sensor failures or communication issues.
- Steering assistance: The ECU uses the steering angle data to determine the amount of steering assistance required and to control the electric motor that assists in steering.
