Description
Hendrickson Suspension Bushing Kit
– Bushing Kit
– Kit Includes:
– (2) Bushing End Plugs (2.875 Inch Diameter, 0.188 Inch Thick)
– (2) Center Beam Bushings (12 Inch Overall Length, 4.75 Inch OD To 3.5 Inch OD, 2.5 Inch ID)
– (4) End Beam Bushings (5.75 Inch Overall Length, 4.375 Inch OD, 2.5 Inch ID)
– (4) Adapter Bolts (6.5 Inch Length With 2.275 Inch Of 3/4 Inch – 16 Thread)
– (4) Lock Nuts (1.106 Inch A/F, 0.63 Inch Height, 3/4 Inch – 16 Thread)
– (8) U-Bolt Washers (0.780 Inch ID, 1.375 Inch OD, 0.188 Inch Thick)
– (8) Adapter Sleeves (2.656 Inch Overall Length, 2.5 Inch OD, 0.781 Inch ID)
– (4) Sleeves (4.13 Inch Length, 2.48 Inch OD, 2.09 Inch ID)
– Sold Individually
– Aftermarket Replacement Part (Not OEM)
– Cross Ref E2864A, E-2864A, R302864A
– This Item Ships Direct From The Manufacturer And Will Arrive In A Separate Package And Possibly A Different Time Than The Balance Of Your Order
Fitment
** Fits Truck Models W/ Hendrickson Rear Suspension
