The Dana Spicer 817099-5219 or 8170995219 is a 1810 series coupling shaft built for heavy-duty driveline applications. The steel tube measures 4.59 inches in diameter with a 0.180-inch wall thickness (116.6 x 4.57 mm), and the tube length is 52.5938 inches (1335.88 mm). Collapsed centerline yoke-to-yoke length is 1630.48 mm, and the centerline yoke-to-center bearing distance is 157.50 mm. The shaft is non-phased (0 degrees). VMRS code 024002062. Sold by Pro Gear and Transmission as a genuine Spicer driveline part. Call us to confirm proper fit for your application.
Features
Dana Spicer 1810 series coupling shaft
Steel tube construction
Tube diameter: 4.59 in. (116.6 mm); wall thickness: 0.180 in. (4.57 mm)
Tube length: 52.5938 in. (1335.88 mm)
Collapsed CL yoke-to-yoke length: 1630.48 mm
Non-phased (0 degrees); CL yoke-to-center bearing: 157.50 mm
Tech Specs
- Series1810
- Shaft MaterialSteel
- InvoiceCOUPLING SHAFT
- Tube Size (MM)116.6 x 4.57
- Tube Size (IN)4.59 x .180
- Tube Length (MM)1335.8813
- Tube Length (IN)52.5938
- CL Yoke To CL Yoke (MM) – COLL1630.4813
- VMRS024002062
- Phased (Yes/No)No
- Phased – Degrees0
- CL Yoke To CL Bearing (MM)157.5000
