Description
The Dana Spicer 817099-3800R or 8170993800R is a 1810 Series coupling shaft built for heavy-duty driveline applications. The welded steel tube measures 4.59 in. outer diameter by 0.180 in. wall thickness and 38.0 in. in length. Collapsed center-line yoke to center-line yoke is 49.60 in.; center-line yoke to center-line bearing measures 43.40 in. The shaft accommodates a 30-degree joint angle and ships with one HR-style universal joint already included. Assembly is welded and non-phased. Sold by Pro Gear and Transmission as a genuine Dana Spicer part. Call us to confirm this shaft fits your specific driveline configuration before ordering.
Features
Dana Spicer 1810 Series coupling shaft
Welded steel tube: 4.59 in. O.D. x 0.180 in. wall, 38.0 in. tube length
Collapsed CL yoke to CL yoke: 49.60 in. (1259.8 mm)
CL yoke to CL bearing: 43.40 in. (1102.4 mm)
30-degree maximum joint angle
Includes one HR-style universal joint; non-phased assembly
Tech Specs
- Series: 1810
- Shaft Material: Steel
- Assembly Type: Welded
- Tube Outer Diameter x Wall Thickness (IN): 4.59 x 0.180
- Tube Outer Diameter x Wall Thickness (MM): 116.6 x 4.57
- Tube Length (IN): 38.00
- Tube Length (MM): 965.2
- CL Yoke to CL Yoke – Collapsed (IN): 49.5984
- CL Yoke to CL Yoke – Collapsed (MM): 1259.8
- CL Yoke to CL Bearing (IN): 43.4016
- CL Yoke to CL Bearing (MM): 1102.4
- Joint Angle: 30 degrees
- U-Joint Style: HR
- Universal Joints Included: Yes, 1
- Phased: No
- VMRS Code: 024002062
