Description
Dana Spicer 1810 Series driveshaft, part number 817093-3110R or 8170933110R, is a welded steel drive shaft engineered for heavy-duty driveline applications. The steel tube measures 4.59 x .180 inches (116.7 x 4.57 mm) with a tube length of 31.3125 inches (795.34 mm). Collapsed center-to-center yoke length is 48.3282 inches (1227.54 mm); installed length is 50.8282 inches (1291.04 mm). Maximum slip is 5.0 inches (127 mm) and mid-slip is 2.5 inches (63.5 mm). The assembly ships with two HR-style universal joints already included. Joint angle is rated at 30 degrees. Not phased. A genuine Dana Spicer part sold by Pro Gear and Transmission. Call us to confirm proper fit for your application.
Features
1810 Series heavy-duty driveline
Welded steel tube: 4.59 x .180 in. (116.7 x 4.57 mm)
Tube length: 31.3125 in. (795.34 mm)
Installed CL-to-CL yoke length: 50.8282 in. (1291.04 mm)
Maximum slip: 5.0 in. (127 mm); mid-slip: 2.5 in. (63.5 mm)
Includes 2 HR-style universal joints; 30-degree joint angle rating
Tech Specs
- Series1810
- Shaft MaterialSteel
- Tube Size4.59 x .180 in. (116.7 x 4.57 mm)
- Tube Length31.3125 in. (795.34 mm)
- Max Slip5.0000 in. (127.0000 mm)
- Mid Slip2.5000 in. (63.5000 mm)
- CL Yoke to CL Yoke – Collapsed48.3282 in. (1227.54 mm)
- CL Yoke to CL Yoke – Installed50.8282 in. (1291.04 mm)
- Joint Angle30 degrees
- U-Joint StyleHR
- Universal Joints IncludedYes – 2
- AssemblyWelded
- PhasedNo
- VMRS Code024000000
