Description
Dana Spicer part number 807369-5208 or 8073695208 is a 1710 series coupling shaft for heavy-duty driveline applications. The steel tube measures 4.000 in. diameter x 0.1338 in. wall thickness and 52.25 in. in length. Collapsed centerline-yoke-to-centerline-yoke length is 62.561 in.; centerline-yoke-to-centerline-bearing distance is 56.971 in. The shaft is phased at 0 degrees (non-phased), accepts a U-joint style 1, and installs with a welded flange connection on one end. No slip assembly. Joint angle is rated at 30 degrees. Not sure this is your part? Call us to confirm proper fit for your application. A genuine Dana Spicer part from Pro Gear and Transmission.
Features
Dana Spicer 1710 series driveline coupling shaft
Steel tube: 4.000 in. diameter x 0.1338 in. wall thickness
Tube length: 52.25 in. (1327.15 mm)
Collapsed CL yoke-to-CL yoke: 62.561 in. (1589.05 mm)
Joint angle: 30 degrees; U-joint style 1 included
Welded flange installation; non-phased (0 degrees); no slip assembly
Tech Specs
- Series: 1710
- Shaft Material: Steel
- Tube Size: 4.000 in. diameter x 0.1338 in. wall (101.6 mm x 3.4 mm)
- Tube Length: 52.25 in. (1327.15 mm)
- CL Yoke to CL Yoke – Collapsed: 62.561 in. (1589.05 mm)
- CL Yoke to CL Bearing: 56.971 in. (1447.05 mm)
- Joint Angle: 30 degrees
- U-Joint Style: 1
- U-Joint Included: Yes
- Installation – CL Yoke to Flange Face: Welded
- Phased: No (0 degrees)
- Slip Assembly: No
- VMRS Code: 024002062
