Description
The Dana Spicer 5002266-3424R or 50022663424R is a welded 1810 series steel driveshaft assembly. The steel tube measures 4.59 inches in diameter by .180-inch wall thickness (116.7 x 4.57 mm), with a tube length of 34.75 inches (882.65 mm). Collapsed center-to-center yoke length is 51.77 inches (1,314.85 mm); installed center-to-center is 54.27 inches (1,378.35 mm). Maximum slip travel is 5.0 inches (127.0 mm) and mid-slip is 2.5 inches (63.5 mm). The assembly includes two HR-style universal joints and is rated for a 30-degree joint angle. The shaft is not phased. Sold by Pro Gear and Transmission. Call us to confirm fitment for your application.
Features
1810 series welded steel driveshaft assembly
Tube size: 4.59 in. diameter x .180 in. wall (116.7 x 4.57 mm)
Tube length: 34.75 in. (882.65 mm)
Collapsed CL-to-CL yoke: 51.77 in. (1,314.85 mm); installed CL-to-CL: 54.27 in. (1,378.35 mm)
Max slip: 5.0 in. (127.0 mm); mid-slip: 2.5 in. (63.5 mm)
Includes 2 HR-style U-joints; 30-degree joint angle; non-phased
Tech Specs
- Series1810
- Shaft MaterialSteel
- InvoiceDrive Shaft
- Tube Size (IN)4.59 x .180
- Tube Size (MM)116.7 x 4.57
- Tube Length (IN)34.7500
- Tube Length (MM)882.6500
- Max Slip (IN)5.0000
- Max Slip (MM)127.0000
- Mid Slip (IN)2.5000
- Mid Slip (MM)63.5000
- CL Yoke To CL Yoke (IN) – Collapsed51.7657
- CL Yoke To CL Yoke (MM) – Collapsed1314.8500
- CL Yoke To CL Yoke (IN) – Installed54.2657
- CL Yoke To CL Yoke (MM) – Installed1378.3500
- Joint Angle30 degrees
- U-Joint StyleHR
- No. of Universal Joints Included2
- Universal Joints IncludedYes
- Unwelded/Welded AssemblyWelded
- PhasedNo
- Phased – Degrees0
- VMRS024000000
