Description
Genuine Dana Spicer Svl Rear Axle Sf for light axle application P/N: 2022613.Limited stock! Don’t miss out! Hassle-free returns and top-notch quality! Authentic Genuine Dana Spicer parts, delivered globally. Need assistance? Our experts have got you covered!
Tech Specs
- Axle ModelGM 8.5/8.6
- MaterialSteel
- InvoiceSVL REAR AXLE SHAFT
- Axle Cover Bolt Hole Qty10
- ABS/Non-ABSNon-ABS
- LocationRear
- Axle Length (In)33.300
- Length (IN)33.300
- Spline Count30 Inboard
- Axle Spline Count30 Inboard
- Bolt Pattern5 X 5.00
- Wheel Stud Hole Diameter (In)0.515
- Brake Pilot Diameter (In)3.091
- Bearing Pilot Diameter (In)1.575
- Cover Bolt Quantity10
- Includes ToneN
- Axle Length (Mm)846.000
- ABS Sensor Ring IncludedNo
- ABS Sensor Ring InstalledN
- Axle Shaft IncludedY
- Axle TypeComplete Assembly
- Bearing IncludedN
- Full-Floating Or Semi-FloatingSemi-Floating
- Inner Axle IncludedY
- Number Of Wheel Lugs5
- Outer Axle IncludedY
- Quantity1
- Retainer Ring IncludedN
- Seal IncludedN
- Seal Kit IncludedN
- U-Joint IncludedN
- Wheel Bearing IncludedN
- Wheel Bolt Prep Kit IncludedN
- Wheel Nuts IncludedN
- Wheel Studs IncludedN
- Length (MM)846.000
