Description
The Dana Spicer Short Couple, part number 10101493, is a 1710 series welded driveline assembly built for heavy-duty applications. Collapsed center-line yoke to center-line yoke measures 314.5 mm (12.38 in.); extended to 431.9 mm when installed. Maximum slip travel is 82.4 mm (3.24 in.), with a mid-slip of 41.2 mm (1.62 in.). Center-line yoke to end of spline sleeve collapses to 355.7 mm (14.00 in.). Two universal joints are included, U-joint style BP, at a 22-degree joint angle. This is a non-phased assembly. Call us to confirm proper fit for your application.
Features
1710 series driveline, welded assembly
Collapsed CL yoke to CL yoke: 314.5 mm (12.38 in.)
Installed CL yoke to CL yoke: 431.9 mm
Maximum slip: 82.4 mm (3.24 in.)
CL yoke to end of spline sleeve (collapsed): 355.7 mm (14.00 in.)
2 U-joints included, style BP, 22-degree joint angle, non-phased
Tech Specs
- Series1710
- Shaft MaterialSteel
- Assembly TypeWelded
- PhasedNo
- Joint Angle (Degrees)22
- U-Joint StyleBP
- No. of Universal Joints Included2
- CL Yoke to CL Yoke – Collapsed (MM)314.5
- CL Yoke to CL Yoke – Collapsed (IN)12.3819
- CL Yoke to CL Yoke – Installed (MM)431.9
- Max Slip (MM)82.4
- Max Slip (IN)3.2441
- Mid Slip / 1/2 Max Slip (MM)41.2
- Mid Slip / 1/2 Max Slip (IN)1.6220
- CL Yoke to End of Spline Sleeve – Collapsed (MM)355.7
- CL Yoke to End of Spline Sleeve – Collapsed (IN)14.0039
- Slip AssemblyNo
- VMRS Code024000000
